Veramo vārtu sistēmas

The drive is equipped with a connecting lever and mechanical limit switches. One sash weighs up to 200 kg.

Full range: two gear and two gearbox versions with or without unlocking system.

The drives are durable: the base box is strong, made of 2.5 mm thick galvanized steel.

Recommended control units: Mindy A3, A3F, A6, A60, A700F; for ME3024 Mindy A824

Easy to use: lockable locking system that can be used indoors and outdoors.
The new system provides a mechanical end stop in the closed position.
The sash opens up to 110 ° as standard, but a 360 ° version is also available.

24 Vdc version for intensive use:

• Easy to program
• Automatic end position memorization
• Pause time programming Partial opening (for pedestrian entrance)
• Deceleration before end positions
• Possibility to connect an alternative energy source (in case of power failure)

Force, N    2000
Current, mA    5000
Speed, m / s    0.016
Power, W    120
feed    230VAC
Security level (IP)    67
Operating temperature, (° C Min / Max)    -20 / + 50
Weight, kg    6
Dimensions, mm    803x110x11
