Iekštelpu detektori

Operating Voltage:    9 to 16 Vdc
Operating Current:    15 mA @ Standby 12v / 40 mA @ Alarm 12v
Detection Range:    Plate 10 m / Tempered 10 m / Laminated 8 m / Wired 8 m / Coated 8 m / Double-pane 8 m / Cutting 3 m
Glass Size:    0.3 x 0.3 m to 3 x 3 m
Glass Thickness:    2.4 x 6.4 m
Alarm Output Relay:    N.C. 50 mA/24 Vdc 10 Ohm in line resistor
Tamper Switch:    N.C. 50 mA/24 Vdc 10 Ohm in line resistor
Static Immunity:    8 kV contact, 15 kV air
Transient Immunity:    2.4 kV @ 1.2 joules
RF Immunity:    10 V/m plus 80% AM from 80MHz to 1GHz
Dimensions:    79 x 48 x 21 mm
Weight:    40 g
